Karaoke Speaker
K10
AT A GLANCE
Real 300W RMS power capacity
HlFl sound for near field application
Two-way with very good phase response
Premium custom made European driver
APPLICATIONS
K10 loudspeaker system is suitable fornear field
HlFl home concert reinforcement installation.
Suitable in spaces like.
-High fidelity music playback
-Multi-functional room
-High-grade solo concert
SPECIFICATIONS
| Power handling (60~15000Hz pink noise 8 hours) | 300W RMS/1200W Peak |
| Nominal impedance | 6 Ohm |
| Frequency response | 55~20000Hz |
| Manufacturing Consistency tolerance | ±2dB from 300 to 10000Hz |
| Average Sensitivity (wideband 100~16000Hz) | 94dB/W/m |
| Calculated Maximum SPL /1m | 118dB continuous/124dB Peak |
| Nominal Directivity (-6dB) | 80°x80° above 1200Hz |
| Low Frequency driver |
Custom made 10"C-sichang driver
Ferrite magnet, 2” In / Out Voice coil |
| High Frequency driver |
1”exit AAUDIO
Neodymiun magnet, 1" coaxial HF |
| Crossover |
Passive mode only
2500Hz,12dB/oct on LF,12dB/oct on HF |
| Connectors | Fasten connector |
| Cabinet |
CNC made with tongue and grove assembly
12+15mm high density wood |
| Finish | white matte PVC |
| Size (WxDxH) | 318x348x518mm |
| Weight | 13.5kg net, 30kg gross(one pair packaging) |
