Karaoke Speaker
K62
AT A GLANCE
Real 100W RMS power capacity (8 hours pink noise)
HIFl sound for near field application
Two-way with very good phase response
Premium custom made European driver
APPLICATIONS
K62 loudspeaker system is suitable fornearfield
HIFl home concert reinforcement installation.
Suitablein spaces like:
-High fidelitymusic playback
-Multi-functionalroom
-High-grade solo concert
SPECIFICATIONS
| Powerhandling (50-15000Hz pink noise 8 hours) | 100W RMS / 40OW Peak |
| Nominal impedance | 4 Ohm |
| Frequency response | 42-20000Hz |
| Manufacturing Consistency tolerance | +2dB from 300 1 10000Hz |
| Average Sensitivity (wideband 100-16000Hz) | 90dB/W/m |
| Calculated Maximum SPL/ 1m | 110dB continuous / 116dB Peak |
| Nominal Dire ctivity (-6dB) | 100°x70° above 1200Hz |
| Low Frequency driver |
Custom made6.5’C-sichangdriver
Ferile magnet, 1" in / Out Voice coil |
| High Frequency driver |
3"paperAAUDlO driver
Ferritle magnet, 1" woice coil HF |
| Crossover |
Passive mode onhy
2800Hz, 12dB/oct on LF, 12dB/oct on HF |
| Connectors | Fasten connector |
| Cabinet |
CNCmade with tongue and grove assembly
12+ 15mm high density wood |
| Finish | white matle Pvc |
| Size (WxDxH) | 220x248x353mm |
| Weight | 6kg net, 8kg gross |
